Radar PCB: A Radio Frequency Circuit for Detection and Automation

Radar PCBs play a vital role in modern automation by enabling systems to detect and respond to their environment. OurPCB offers expert PCBA services that ensure the reliable assembly of these complex circuits. With our support, you can develop efficient radar PCBs that enhance object detection and target tracking capabilities.
Quote Form
check whiteFast Turnaround check whiteISO Certified
1 2 3

Technological advances have pushed us to create systems that interact with the environment and then make decisions appropriately. Such a level of automation requires powerful hardware to send and receive signals from the surrounding environment.Radar PCBs are critical hardware for this job because they assist in detecting objects or spotting targets. There's much more to learn about these circuits, so let's get right into it.



What is Radar PCB?



A radar PCB is an electrical circuit responsible for producing, transmitting, and receiving radio frequency signals.

It contains an antenna structure mounted on a high-frequency laminate material that transmits a radar lobe generated by the RF circuit.

Also, the same antenna receives the reflected radar pulse after hitting an object, and the RF circuit analyzes it.

Usually, the modern radar PCB features a digital circuit at the rear for analyzing the echo while the RF and antenna sections sit at the front.



The Fundamental Parts Of A Radar PCB



The essential parts of a radar PCB include:

  • Transmitter: A signal from the waveform generator is not strong enough for radar. Therefore, the purpose of a transmitter is to amplify the signal using a power amplifier.
  • Receiver: A receiver detects and processes the reflected signal using a receiver processor, like the super-heterodyne.
  • Antenna: Contains parabolic reflectors, planar arrays, or electronically steered phased arrays. It is responsible for sending out and receiving the pulses.
  • Duplexer: A duplexer is a device that enables the antenna to do the tasks of a transmitter and receiver.
  • Waveguides: Waveguides are the transmission lines for transmitting radar signals.
  • Threshold Decision: This part compares the output from the receiver to the threshold to determine the presence of an object. After comparison, if the work falls below the point, you assume noise exists.



A Radar PCB's Critical Aspects



Range



A radar features an antenna that sends a light-speed signal to the target. After hitting an object, this signal gets reflected in the antenna. This distance between the radar and the thing defines the range. Usually, a wide range is better because it enables you to reach far-away targets.



Pulse Repetition Frequency





Radar signal delivery should be at every clock cycle with an appropriate delay interval between the clock cycles. Ideally, the device should receive the signal's echo before transmitting the next pulse.

Likewise, a radar PCB operates similarly, sending periodic signals forming a wave of narrow rectangular pulses.

The delay between two clock pulses forms the pulse repetition time. With that in mind, pulse repetition frequency is the inverse of pulse repetition time. It defines the number of times the radar PCB sends out the signal.



Maximum Unambiguous Range



Each clock pulse should transmit a signal. However, you can only receive the echo for the current clock pulse after the following one if the interval between the two is short.

But you will note that the target's range is shorter than it should be. Therefore, you must choose the delay between the intervals wisely.

Ideally, you should receive the echo for the current clock pulse before the next one goes out. This way, the signals will give you a clear picture of the object's actual range, the maximum unambiguous range.



Minimum Range



Compared to the range, the minimum coverage is when the echo takes to get to the antenna after the first pulse width transmission.



Types Of Radar PCB



There are five types of radar PCBs. They include:



Doppler Radar PCB



As the name suggests, this type uses the Doppler effect to determine the data speed for objects within a specific distance.

It sends electromagnetic signals to the object and then measures how the target affects the echo's signal frequency.

It is possible to determine an object's velocity with the radar as the reference for the measurement and adjustment.



Monopulse Radar PCB



Monopulse radar PCBs contrast the received signal using a specific pulse by comparing the signal's characteristics as previously observed.

The most common type is the conical scanning radar circuit. It checks the results of the two methods to measure the object's position directly.



Passive Radar PCB



A passive radar PCB is a detection device that processes ambient illumination information. After that, it assists in pursuing targets.



Weather Radar PCB



Wind and weather detection is critical in today's world, and weather radar PCBs help with that by using radio frequency signals. However, there is a tradeoff between precipitation reflection due to atmospheric moisture and attenuation.

Similarly, you can use a weather radar that features Doppler shifts to measure wind speed and dual-polarization for determining the type of rainfall.



Pulsed Radar PCB



Lastly, this PCB type shoots high-frequency, high-intensity pulses at the target, then waits for the bounce-back signal before firing again.

To clarify, using the Doppler shift technique, the repetitive firing frequency determines the radar PCB's range and resolution. This technique senses moving objects from the echoed signal in the following manner:

  • When bounced back, signals from static objects are in phase and cancel out.
  • When Pulses from moving objects have phase differences.



What is a Millimeter-Wave Radar PCB Technology?



A millimeter-wave radar PCB is a critical component of ADAS (Advanced Driver Assistance Systems) for running an autopilot vehicle. However, running requires multiple parts, including materials that handle 77GHz millimeter-wave radar and higher.

Indeed, these 77GHzmm-wave radar PCBs have different construction material requirements than those operating at microwave and lower radio frequencies.

The reason is that the 77GHzmm-wave radar system module produces a shorter wavelength. Therefore, it needs thin circuit materials placed independently of the circuit design's transmission line architecture.



Special Offer: Get $100 off your order!

Enjoy $100 off your order! No hidden fees and no minimum order quantity required.
Email [email protected] to get started!

What is an ADAS Radar PCB?



In short, ADAS (Advanced Driver Assistance System) is an automotive safety system. It gathers data from the environmental conditions inside and outside the vehicle for object detection.



To clarify, the active safety system operates at millimeter-wave frequencies. Also, it uses various automotive radar sensors to identify and detect static or dynamic objects.

Indeed, the 77GHzmm-wave radar sensor has proven effective in automotive applications over time. Additionally, it plays a vital role in developing advanced driving assistance algorithms for self-driving vehicles.



Where Do You Find Radar PCBs?



Nautical maps, missile guiding, air defense, and enemy identification systems use radar PCBs for enhanced precision.



Military Use



Nautical maps, missile guiding, air defense, and enemy identification systems use radar PCBs for enhanced precision.



Controlling Air Traffic



Radar PCBs also come in handy in air surveillance equipment to help pinpoint aircraft positions close to ground vehicles and airports. Additionally, they help aircraft land safely in bad weather.



Remote Sensing



Similarly, navigation on the sea requires sensitive remote sensing equipment containing radar PCBs to help detect icebergs and sea vessels.



Ground Traffic Control



Ground traffic control systems also need radar PCBs to manage traffic, control congestion, and monitor vehicle speeds like air traffic control.



Space Application



Similarly, radar PCBs allow for safe navigation and landing of spaceships. Also, they help in tracking and monitoring satellites, planets, meteors, etc.



Other applications include the following: automatic door openers, fire & trespassing alarms, intelligent lights, level meters, and autonomous driving.



Materials Used For Radar PCB



Manufacturers use two primary materials to make these PCBs:



Epoxy-Based



A hydrocarbon resin matrix mixes inorganic fillers and woven glass forms epoxy-based materials. This combination reduces the oxidation process while allowing low-profile copper film usage.



Polytetrafluoroethylene (PTFE)



PTFE is a synthetic fluoropolymer commonly used in either single, double-sided, or multi-layer boards with few layers. For fabrication, you can use high-frequency circuit material with woven glass or inorganic fillers.



Advantages of Radar PCBs



  • Radar PCB signals can penetrate clouds and materials like rubber.
  • The radar PCB circuitry can determine an object's velocity, distance, and position when in motion.
  • Signals/pulses from a radar PCB don't need a medium (wire) for transmission because they can travel through space, water, and air.
  • The PCB operates at a high frequency to hold large amounts of data.
  • Signals from a radar PCB can cover large areas without requiring extra costs.



Design Steps In Radar PCBs



Fabricating a radar PCB involves the following steps:



Conceptualization



Conceptualization enables you to determine the circuit board's intended use. Remember, you can apply a radar PCB in different areas, like automotive (millimeter-wave), industrial applications, etc.

Likewise, consider the operating temperature, component population, board size, and other features.



Schematics



Next is drawing a schematic diagram, which includes all the component details and helps develop the bill of materials.



Creation of Block Diagram



The third is the creation of a block diagram. A radar PCB block diagram describes the board architecture & dimensions and illustrates areas for attaching components and other features.



Manufacturing Process



Manufacturing involves the actual radar PCB fabrication, and you should consider factors like the stack up and material.



Component Placement



When placing the electronic components (surface mount technology, thru-hole, etc.), consider the position, density, order of positioning, the routing process, and circuit priority.

Efficient positioning by keeping the components close and ensuring the traces are short minimizes circuit loss.



Components in a PCB

Components in a PCB



Circuit Routing



Circuit routing involves connecting a radar PCB active components as per their priority. As a general rule of thumb, you should begin with the most delicate circuitry and then the rest to avoid interference.



Common Types of Radar PCB Failure Analysis Tests



Cross Sectioning



Cross-sectioning is a destructive testing sequence. That is to say; it involves the precise separation and removal of the relevant electronic component from the radar PCB. The process comes in handy when determining defects in these areas:

  • Component defects
  • Raw materials evaluation
  • Processing issues caused by reflow soldering
  • Shorts or opens
  • Failures resulting from thermomechanical forces



Solderability Examination



Incorrect solder mask application and oxidation are the most common causes of radar PCB failure. Thus, solderability examination is a crucial testing procedure.

The process checks the strength and quality of the solder wetting to simulate the solder contact. Hence, it is ideal for PCB coating, solder & flux evaluation, quality control, and benchmarking.



Radar PCB Contamination Testing



Even though radar PCB manufacturing and assembly occur in clean environments, contamination might occur. A contamination test uses the following methods and elements to prevent infections.

  • Hot air leveling fluxes
  • Water-soluble soldering
  • Electrolytic solutions
  • Copper etching liquid



Scanning Electron Microscopy



Scanning electron microscopy is one of the fastest and most precise testing procedures. Therefore, it is ideal for checking defects, flaws, and issues relating to assembly & soldering.

It uses a visibly lit, high-powered microscope to detect poor construction and reveal defects in specific cross-sections.

Also, you can use this method to study the semiconductor die's metallization, quality, and integrity. Scanning electron microscopy can check the minor flaws, just a few broad nanometers.



X-ray Examination



There are three types of X-ray examinations: essential film, real-time, and 3-dimensional. Each technique highlights concealed components and those with hidden joints in a non-destructive way.

X-rays allow interior inspection of the following: internal wire dress, sealing lid voids, excessive, insufficient, or poor solder, die-attach quality, interior particles, and trace integrity of the substrate/printing wiring board.



Summary



As you can see, radar PCBs are critical in modern and emerging technologies, especially as we enter the era of autonomous cars. Therefore, if you need one for your project or have any questions, contact us for more details.
