MCP6004 Datasheet: How this High Gain Op-Amp works

Amplification is a key element in many modern technologies, especially in audio applications. The MCP6004 quad Op-Amp stands out for its high bandwidth gain and low power consumption, making it a popular choice for various designs. At OurPCB, we offer PCBA services that can help you efficiently assemble and integrate the MCP6004 into your projects, ensuring optimal performance for your amplification needs.
Quote Form
check whiteFast Turnaround check whiteISO Certified check whitePremium Quality
1 2 3
Table of Contents

About the MCP6004 datasheet, Nearly every modern technology relies on amplification.

The operational amplifiers, for example, are essential in audio designs and other general-purpose applications.

But certain Op-Amps provide more functionality than others.

An example, in this case, is the MCP6004 quad Op-Amp.

There are several reasons the MCP6004 general-purpose Op-Amp is popular.

Its technical specifications offer a significant bandwidth gain, an extended temperature range, a vast capacitive load, etc.

Read on to find out more about this operational amplifier.



What is MCP6004?



The MCP6004 is one of the general-purpose Quad Op-Amps that belong to the MCP600X family from Microchip Technology Inc.

These quad Op-Amp 14-Pin package ICs are famous for high bandwidth gain and low power production.

Therefore, the MCP6004 is a known gain bandwidth product (GBWP) because it yields 1MHz.


A circuit diagram showing a non-inverting Op-Amp operation

(A circuit diagram showing a non-inverting Op-Amp operation).



Pin Configuration



Pin Number Name of pin Pin Description
1,7, 8, and 14 Vout pins A, B, C, and D. They represent the four Op-amps output pins.
2,6,9, and 13 VIN- pins A, B, C, and D These are the four op-amps inverting input pins.
3,5,10, and 12 VIN+ pins A, B, C, and D On the other hand, these are the four op-amps non-inverting input pins.
4 VD It serves as the positive terminal or supply rail.
11 Vss Meanwhile, this is the negative rail or ground terminal.
MCP6004 PINOUT DIAGRAM

(MCP6004 PINOUT DIAGRAM)



Special Offer: Get $100 off your order!

Claim your $100 discount by sending an inquiry today. Act now to save on your next project!
Please email [email protected] for details.

Features



  • The MCP6004 Op-Amp has a 1.8MHz bandwidth and is a low-power op-amp.
  • It has a supply and operating voltage range between 1.8V and 6V.
  • Quiescent current is rated at 10uA.
  • In terms of output pin current, it uses 30mA.
  • Similarly, it uses a rail-to-rail output and input.
  • The standard mode input voltage range starts at 300 mV.
  • Meanwhile, its standard mode rejection ratio is approx. 76dB.
  • It has a 112dB open loop gain.
  • MCP6004 is available in the following packages: 14-Pin PDIP, 24-Pin GDIP, and 36-Pin PDSO.



MCP6004 Equivalents



TLV9004

Other Quad Op-Amps



TL084, LM324.

The LM324 Quad Op-Amp

(The LM324 Quad Op-Amp).



MCP6004 Application Circuits



  1. Instrumentation Amplifier using Unity-Gain Buffer Input.
  1. Peak Detector circuits using CMOS Analog Switches.

A Peak Detector tuner with Analog Switches

(A Peak Detector tuner with Analog Switches).



  1. Active Second-Order Low-Pass Filters.





7. Applications

  • It is an automotive general-purpose amplifier.
  • Similarly, it is helpful in general-purpose equipment like portable audio players.
  • It is an essential part of Photodiode Amplifiers.
  • Also, it is a crucial component of Analog tuners and Analog filters.
  • It is essential in electronics like Notebooks and PDAs.
  • It is in most battery-powered Systems.

A speaker showing amplified sound waves

(A speaker showing amplified sound waves)



Conclusion

The MCP6004 is a quad Op-Amp 14-Pin package.

It is most notable for its high slew rate, bandwidth gain, and low supply voltage.
